5A03 Aluminum alloy sheet profile forgings

5A03 Aluminum alloy sheet profile forgings

5A03 aluminium alloy sheet profile forgings is an alloy with moderate Mg content in 5 * * * system, with low strength and high plasticity. Cold deformation can improve its strength, but the plasticity will decrease. In aircraft manufacturing, we need to manufacture welded medium load parts, such as pipes, liquid containers and skeletons, which need high technological plasticity and high corrosion resistance.

The melting temperature of 5A03 is 700~750 ℃, and the casting temperature is 690~730℃. 5A03 alloy has quite high corrosion resistance. The die forging temperature of 5A03 is 420~475℃, and the deformation rate in this temperature range is more than 80%. 5A03 alloy wire does not form weld when it is made of solder, and the strength of the weld can be 90%~95% of the matrix material, and it has high plasticity at the same time. The machinability and grinding performance of the O state material are not good, and the H state material is better.

5A03 Aluminum

aluminum 5a03

aerospace aluminum forging

aircraft aluminum forgings

aircraft aluminum forgings

aerospace aluminum forging

aluminum 5a03

5A03 Aluminum

aerospace aluminum forging

Calibration mechanical strength of 5A03 aluminum alloy sheet profile forgings
Technical standard Type Temper δ  or d/mm Tension strength Rm/Mpa Rp0.2/Mpa A/%
GB/T 3880 Aluminum sheet O 0.5~4.5 ≤195 ≥100 ≥16
H14 >0.5~4.5 ≥225 ≥195 ≥8
H24
H34
H112 >4.5~10.0 ≥185 ≥80 ≥16
>10.0~12.5 ≥175 ≥70 ≥13
>12.5~25.0 ≥175 ≥70 ≥13
>25.0~80.0 ≥165 ≥60 ≥12
GJB 2503 Aluminum sheet O 0.5~4.0 ≤196 ≥98 ≥15
H×4 0.5~4.0 ≥225 ≥196 ≥8
GJB 2662 Aluminum plate
H112
7~10 ≥186 ≥78 ≥15
>10~25 ≥176 ≥67 ≥12
>25~50 ≥167 ≥59 ≥11
GB/T 3191 Extruded aluminum round bar H112, O ≤150 ≥176

≥78 ≥13
GJB 2504 Extruded aluminum round bar 5~250
HB 5202 Extruded aluminum round bar ≤240
GJB 2507 Extruded aluminum round bar H112, O All ≥176 ≥78 ≥12
GB/T 4437 Aluminum pipe H112 All ≥176 ≥69 ≥15
GJB 2381   H112, O OD25~250
Wall thickness 5~35
≤240
GJB 2379 Cold drawn aluminum pipe O All ≤177 ≥78 ≥15
H×4 All ≥215 ≥127 ≥8
GJB 2351 Free forgings, die forgings H112 As agreed ≥186 ≥78 ≥15
HB 5204
