5A02 aluminum alloy sheet profile forgings wire

5A02 aluminum alloy sheet profile forgings wire

5A02 alloy with low strength, high plasticity, cold deformation can improve its strength, but will reduce the plasticity, have good mixing performance in welding hydrogen welding, welding and friction contact, can also be welding, high corrosion resistance. The welding of medium load in aircraft manufacturing requires high technological plastic and corrosion resistant parts, such as pipes, liquid containers and slippery frames.

The melting temperature of 5A02 is 700~750℃, and the casting temperature is 690~730℃. Alloy wires are used as solders and rivets. The machinability of 5A02 O is not good, and it is improved in the condition of cold hardening. The 5A02 surface treatment process is equivalent to other aluminum alloys, but it is much worse than the 6063 alloy.

aluminum 5a02

5a02 aluminum

aerospace extruded aluminum

aluminum 5a02

5a02 aluminum

aerospace extruded aluminum

aerospace extruded aluminum

5a02 aluminum

aluminum 5a02

aluminum 5a02

5a02 aluminum

aerospace extruded aluminum

Chemical composition of 5A02 alloy
Alloy Si Fe Cu Mn Mg Zn Ti Others Al
Each Total
5A02 0.4 0.4 0.1 0.15~0.40 2.0~2.8 0.6(Si+Fe) 0.15 0.05 0.15 Remainder

Calibration mechanical strength of 5A02 Aluminum alloy sheet profile forgings wire
Technical Standard Type Temper δ  or d/mm Tension Strength Rm A/%
Not less than
GB/T 3880 Aluminum sheet O 0.5~1.0 167~225 ≥17
>1.0~10.0 ≥19
H14 >0.5~1.0
>1.0~4.5
≥235 ≥4
≥6
H24
H34
H18 >0.5~1.0 ≥265 ≥3
>1.0~4.5 ≥4
H112 >4.5~12.5 ≥175
≥155
≥7
>12.5~25.0 ≥7
>25.0~80.0 ≥6
GJB 2503 Aluminum sheet O 0.5~1.0 167~225 ≥16
>1.0~4.0 ≥18
H×4 0.5~1.0 ≥235 ≥4
>1.0~4.0 ≥6
H×8 0.5~1.0 ≥265 ≥3
>1.0~4.0 ≥4
GJB 2662 Aluminum plate O >4~10 167~225 ≥18
H112 7~25 ≥175 ≥7
>25~50 ≥157 ≥6
GB/T 3191 Extruded aluminum round bar H112, O ≤150 ≤225
≥10
GJB 2504 Extruded aluminum round bar 5~250
HB 5202 Extruded aluminum round bar ≤240
GJB 2507 Extruded aluminum round bar H112, O All ≤225 ≥12
GB/T 4437 Aluminum tube H112 All ≤225
GJB 2381 H112, O OD25~250
Wall thickness5~35
≤240
GJB 2379 Cold drawn tube O All 165~225
H×4 All ≥205
H×8 OD<50,
Wall thickenss≤5.0
≥225
OD≥50,
Wall thickness≤5.0
≥215
GJB 2351 Free forgings、Die forgings H112 As agreement ≥177 ≥15
HB 5204
GB/T 3196
GJB 2055
Aluminum wire H×8 1.6~10.0 ≥118
